(ø 100-500 mm.)
Nordfab Quick-fit duct system
is manufactured from fully galvanized sheets and is characterized by great stability of form and a smooth surface. The components have a rolled collar,over which the Nordfab Q-F clip is fitted. The clip has an inner gasket to ensure that an air tight seal is achieved. It requires no tools to assemble ormodify.
The Nordfab Quick-Fit system has a complete accessory range wigh 60° Y-pieces, 30° branches, 30° cut in branch, 90° adapters, reducers, sliding
dampers, automatic dampers etc. It ensures individual fitting and great flexibility-including adaptation to other duct systems.
| ØA | Parts No. | ENDS | ØB,ØC | THICKNESS | WEIGHT (Kg) |
| 100 | QG100 xxx xxx | QF | 100 | 0.7 | 1.13 |
| 125 | QG125 xxx xxx | QF | ≤125 | 0.7 | 1.62 |
| 140 | QG140 xxx xxx | QF | ≤140 | 0.7 | 1.96 |
| 160 | QG160 xxx xxx | QF | ≤160 | 0.7 | 2.46 |
| 180 | QG180 xxx xxx | QF | ≤180 | 0.7 | 3.01 |
| 200 | QG200 xxx xxx | QF | ≤200 | 0.7 | 3.62 |
| 250 | QG250 xxx xxx | QF | ≤250 | 0.7 | 5.38 |
| 315 | QG315 xxx xxx | QF | ≤315 | 0.7 | 8.18 |
| 350 | QG350 xxx xxx | QF | ≤350 | 0.7 | 9.92 |
| 400 | QG400 xxx xxx | QF | ≤400 | 0.7 | 12.71 |
| 450 | QG450 xxx xxx | QF | ≤450 | 0.7 | 15.84 |
| 500 | QG500 xxx xxx | QF | ≤500 | 0.7 | 19.30 |
